FLT-6020EN




FLT-6020EN is a mid-end high-profile Pipe laser cutting machine developed by Jinqiang Laser for pipe-type sheet metal processing. Equipped with a standard automatic loading and unloading device, it can realize the feeding of the materials, reduce the labor saving time and help the customers to reduce the production cost.

From the configuration selection to the assembly process, to the later training and after-sales service, the machine truly creates a laser cutting machine that customers can use!



 Tube cutting working area

Φ15mm-φ220mm,L=6000mm;≤200mm)

X,Y axis positioning accuracy

±0.03mm/m

X,Y axis repeat positioning accuracy

±0.02mm/m

X,Y axis max speed

80m/min

X,Y axis max acceleration

0.8G

Max.turning speed

80rpm

Max.cutting speed

25m/min

CNC system



Tailings length

≥200mm

Voltage/Power

380V/50HZ  /  25KW

Dimension(L×W×H)

10500mm×4600mm×2400mm
