JQ-2040H



Processing area(L×W)

4000mm×2000mm

Power

4000W/6000W/8000W

X axis track

2020mm

Y axis track

4020mm

Z axis track

300mm

X,Y axis positioning accuracy

±0.03mm/m

X,Y axis repeat positioning accuracy

±0.02mm/m

X,Y axis max speed

120m/min

X,Y axis max acceleration

1.2G

Max.load of worktable

1500Kg

CNC system



Voltage/Power

380V/50HZ  /  35KW

Dimension(L×W×H)

9500mm×47400mm×2500mm
